Clonorchiasis

[Clonorchis sinensis]

Causal Agents

The trematode Clonorchis sinensis (Chinese or oriental liver fluke) is an important foodborne pathogen and cause of liver disease in Asia. This appears to be the only species in the genus involved in human infection.

Life Cycle

Clonorchis sinensis eggs are discharged in the biliary ducts and in the stool in an embryonated state image . Eggs are ingested by a suitable snail intermediate host image . Eggs release miracidia image , which go through several developmental stages (sporocysts image , rediae image , and cercariae image ). The cercariae are released from the snail and, after a short period of free-swimming time in water, they come in contact and penetrate the flesh of freshwater fish, where they encyst as metacercariae image . Infection of humans occurs by ingestion of undercooked, salted, pickled, or smoked freshwater fish image . After ingestion, the metacercariae excyst in the duodenum image and ascend the biliary tract through the ampulla of Vater image . Maturation takes approximately one month. The adult flukes (measuring 10 to 25 mm by 3 to 5 mm) reside in small and medium sized biliary ducts.

Hosts

The host range is relatively broad and C. sinensis is able to infect multiple species of snails and more than 100 species of freshwater fish as intermediate hosts. Many of the fish species belong to the Cyprinidae family, which includes carps and minnows. Additionally, C. sinensis metacercariae have been recovered from some species of shrimp in China and may contribute to disease transmission in these locations, although prevalence and metacercarial burdens are much lower than in cyprinid fish. Other than humans, domestic canids and felids, swine, mustelids, and other piscivorous mammals can serve as definitive hosts.

Geographic Distribution

Endemic areas are in East Asia (including Korea, China, Taiwan, and northern Vietnam) and into far eastern Russia. Cases of clonorchiasis have been reported in non-endemic areas, including the United States, typically in Asian immigrants, or following ingestion of infected undercooked/pickled freshwater fish imported from endemic areas.

Clinical Presentation

Symptoms are related to worm burden; most infections are of light burden and asymptomatic. Clinical manifestations result from inflammation, intermittent obstruction of the biliary ducts, mechanical injury resulting from worms feeding on mucosal tissue, toxic effects of worms’ metabolic products, and secondary bacterial infections. In mild cases, manifestations include mild abdominal symptoms. Patients with high worm burdens often have other nonspecific symptoms such as abdominal pain (particularly in the right upper abdominal quadrant) and various somatic symptoms (e.g. headache, dizziness). With infections of longer duration, the symptoms can be more severe, and hepatomegaly and malnutrition may be present. More rarely, biliary complications (e.g., cholangitis, cholelithiasis, cholecystitis, and cholangiocarcinoma), pancreatitis, and liver abscesses may develop.



Clonorchis sinensis eggs.



Clonorchis sinensis eggs are small, ranging in size from 27 to 35 µm by 11 to 20 µm. The eggs are oval shaped with a convex operculum that rests on visible “shoulders” at the smaller end of the egg. At the opposite (abopercular) end, a small knob or hook-like protrusion is often visible. The miracidium is visible inside the egg. Eggs of C. sinensis are highly morphologically similar to Opisthorchis spp.

Figure A: C. sinensis egg: the small knob at the abopercular end is visible in this image.
Figure B: C. sinensis egg. Note the operculum resting on "shoulders;" image taken at 400× magnification.
Figure C: C. sinensis egg; image taken at 400× magnification.
Figure D: C. sinensis egg; image taken at 400× magnification.
C. sinensis adults.



Clonorchis sinensis adults are flattened, lance shaped, and measure approximately 10 to 25 mm long by 3 to 5 mm wide. The oral and ventral suckers (acetabulum) are relatively small. Like other flukes, they are hermaphroditic. The two testes are located posterior to the ovary, and are highly branched–a feature which separates it from the related Opisthorchis spp. (rounded testes). Adults reside in the biliary passages of the liver of the definitive host.

Figure A: Adult of C. sinensis.
C. sinensis
Figure B: Adult of C. sinensis stained with carmine. Clearly visible in this image are the oral sucker (OS), pharynx (PH), ceca (CE), ventral sucker (acetabulum) (VS), uterus (UT), vitellaria (VT), and testes (TE).
Snail intermediate hosts of C. sinensis.
Figure A: Shells of Parafossarulus manchouricus, the most common snail host of C. sinensis in endemic areas in southeast Asia. Image courtesy of the Web Atlas of Medical Parasitology and the Korean Society for Parasitology.
Figure B: Bithynia sp., another common intermediate host of C. sinensis. Image courtesy of Michal Maňas.

Laboratory Diagnosis

Diagnosis is usually based on microscopic identification of eggs in stool specimens. However, the eggs of Clonorchis are practically indistinguishable from those of Opisthorchis  . Adult flukes have been recovered at surgery or may be spontaneously passed after anthelmintic treatment. Morphologic examination of the intact adult fluke allows definitive species identification.

Serologic testing is currently not available for Clonorchis infection in the United States.

Laboratory Safety

Standard precautions for the processing of stool samples apply. C. sinensis eggs in feces are not infectious to humans.

Suggested Reading

Qian M.B., Utzinger J., Keiser J., and Zhou XN, 2016. Clonorchiasis. Lancet, 387 (10020), pp. 800–810.

Saijuntha W., Sithithaworn P., Kaitsopit N., Andrews R.H., Petney T.N., 2014. Liver Flukes: Clonorchis and Opisthorchis. In: Toledo R., Fried B. (eds) Digenetic Trematodes. Advances in Experimental Medicine and Biology, vol 766. Springer, New York, NY.

Petney, T.N., Andrews, R.H., Saijuntha, W., Wenz-Mücke, A. and Sithithaworn, P., 2013. The zoonotic, fish-borne liver flukes Clonorchis sinensis, Opisthorchis felineus and Opisthorchis viverrini. International Journal for Parasitology, 43 (12–13), pp.1031–1046.

Hong S.T., Fang Y., 2012. Clonorchis sinensis and clonorchiasis, and update. Parasitology International, 61(1), pp. 17–24.

Kaewkes S., 2003. Taxonomy and biology of liver flukes. Acta Tropica, 88 (3). pp. 177–86.

DPDx is an educational resource designed for health professionals and laboratory scientists. For an overview including prevention, control, and treatment visit www.cdc.gov/parasites/.
